| General | |
| CPU | Intel®8th/10th Whiskey lake-U&Coffeelake-U&Cometlake Processor |
| Chipset | Intel® SOC |
| Memory | 2*SO-DIMM DDR4 3200MHz Max 64GB |
| Storage | 1*SATA3.0 1*M.2 Key M (Supports Sata&PCIe NVMe SSD adaptive) |
| Expansion Interface | 1*M.2 Key E （Supports WiFi+Bluetooth extension） 1*Mini PCIe (Supports Wifi+Bluetooth /4G expansion modules) 1*SIM card slot |
| BIOS | AMI BIOS |
| System | Windows 10/11 32bit/64bit/Linux |
| I/O Interface | |
| Ethernet | 1/2*Realtek® RTL8111 1Gbps Ethernet Controller，RJ45 |
| Serial | 4*COM232 (COM1 supports RS232/485 as an option) |
| USB | 4*USB 3.0，3/5*USB 2.0 |
| Audio | Onboard audio decoding controller ALC897 + NS4251 default power amplifier support 3 w @ 4 Ω; 1.7W@8Ω max |
| Others | 1*4PIN ATX Header 1*TPM Header 1*CPU FAN Header 1*R_USB Header（Extensible 1*USB2.0） 1*GPIO Header 1*SPEAKER Header 1*F_PANEL Header 1*JAT Header 1*SATA interface 1*SATA_PWR Header 4*COM232 Header |
| Display | |
| Display Interface | 2*HDMI、1*DP (Support 3 display synchronous/asynchronous output) |
| Mechanical & Environment | |
| Dimension | 121mmX121mm |
| Power Input | DC 12V-19V input power supply |
| Temperature | Operation: 0℃~60℃, Storage: -20℃~75℃ |
| Relative Humidity | 0% ~ 95%, non-condensing |
WKNANO-WHLUT-4C2L
Intel®8th/10th Whiskey lake-U&Coffeelake-U&Cometlake Processor；Intel® SOC；2*SO-DIMM；4*USB3.0；3/5*USB2.0；1*SATA3.0；4*COM232；2*M.2；1*TPM
processor：Intel®8th/10th Whiskey lake-U&Coffeelake-U&Cometlake Processor
chipset：Intel® SOC
Display: Intel® UHD Graphics
memory：2*SO-DIMM DDR4 3200MHz Max 64GB
Display output：2*HDMI、1*DP (Support 3 display synchronous/asynchronous output)
storage：1*SATA3.0；1*M.2 Key M (Supports Sata&PCIe NVMe SSD adaptive)
USB:4*USB 3.0，3/5*USB 2.0
supports 4*COM232 (COM1 supports RS232/485 as an option)
On board 1/2 * RTL8111 gigabit network card
Expansion slot：1*M.2 Key E （Supports WiFi+Bluetooth extension）
Expansion slot：1*Mini PCIe (Supports Wifi+Bluetooth /4G expansion modules) 1*SIM card slot
